Lightning ZEV4 Zero Emission Type A School Bus

The Lightning ZEV4 Type A school bus built in partnership with Collins Bus Corporation is the ideal small school bus solution for transporting students with no emissions.   Equipped by Lightning eMotors with a state-of-the-art electric powertrain, it provides a quiet, safe, smooth and familiar driving experience that your drivers  and students will love.

It is available on a choice of two trusted and widely-used platforms:
  • GMC Savana 4500 / Chevrolet Express 4500
  • Ford E-450

Available with an estimated 130-mile range, this vehicle provides practical, reliable service while producing zero emissions on the road. Charging is simple and quick, with both Level 2 AC charging and DC Fast Charge supported.   We use the highest-quality components available, including thermally-managed batteries which deliver the best range, efficiency and lifetime of any batteries in the market.   Our close partnership with Collins Bus makes electric school buses easy to purchase through their dealer network.

  • Battery-electric vehicle
  • Smooth, quick and quiet
  • Engineered and built in the USA
  • Elegant cabin integration with batteries fully under the floor
  • CARB certified and HVIP eligible
  • Lightning Insights provides understanding of usage and efficiency

Base Chassis Ford E-450 Cutaway GMC Savana 4500 Cutaway
GVWR 14,500 lbs 14,200 lbs
Minimum Wheelbase 158 in 159 in
Driving range* up to 130 miles up to 130 miles
Battery Capacity 125 kWh 120 kWh
Charge Time 7.5 - 8.5 hours(Level 2 at up to 13.2 kW) 2 - 2.5 hours (DC Fast Charge at up to 80 kW) 7 - 8 hours(Level 2 at up to 13.2 kW) 1.5 - 2 hours (DC Fast Charge at up to 80 kW)
Charging options Level 2 AC (up to 13.2 kW) and DC Fast Charge (up to 80 kW) with J1772 CCS-1 Combo
Passenger capacity** up to 24
Maximum Speed 65 mph (electronically limited)
Peak Power 241 HP (180 kW)
Torque Rating (after transmission) 790 lb-ft (1071 Nm)
Warranty • Base Chassis: Ford standard warranty • Electric powertrain and batteries: Lightning eMotors standard warranty (5 year / 60,000 miles) • Base Chassis: GM standard warranty • Electric powertrain and batteries: Lightning eMotors standard warranty (5 year / 60,000 miles)
Telematics: Lightning Insights • Preventive Maintenance • Range Analysis • Driver Behavior • Charger Management
